O Switch Hikvision DS-3E1326P-EI/M é uma solução robusta e confiável para redes de segurança que necessitam de alta capacidade de conexão e alimentação PoE. Com 24 portas PoE de 10/100 Mbps, 1 porta Gigabit combo e 1 porta Gigabit RJ45, ele oferece um orçamento total de potência PoE de 230W, ideal para suportar múltiplos dispositivos como câmeras IP e access points.

Este switch também possui recursos avançados como suporte a VLAN 802.1Q, PoE Watchdog para reiniciar automaticamente câmeras que não respondem, e prevenção de loops STP/RSTP, garantindo estabilidade na rede.

Com capacidade de transmissão PoE de longo alcance de até 300 metros, detecção de falhas no cabeamento e proteção contra surtos de 6kV, é perfeito para redes que exigem desempenho, segurança e confiabilidade.



• General

• Shell

  Metal material

• Net Weight

  2.13 kg (4.7 lb)

• Gross Weight

  3.1 kg (6.8 lb)

• Dimensions (W × H × D)

  440.00 mm × 44.00 mm × 220.80 mm (17.32'' × 1.73'' × 8.69'')

• Operating Temperature

  0 °C to 45 °C (0 °F to 113 °F)

• Storage Temperature

  -40 °C to 85 °C (-40 °F to 185 °F)

• Operating Humidity

  5% to 95% (no condensation)

• Relative Humidity

  5% to 95% (no condensation)

• Power Supply

  100-240 VAC, 50/60 Hz, Max. 4 A

• Installation Mode

  Rack (equipped with mounting ears)

• Max. Power Consumption

  250 W

• Power Consumption in Idle

  20 W

• Surge Protection

  6 kV

• Network Parameters

• Portos

  24 × 10/100 Mbps PoE port,1 × Gigabit combo,1 × Gigabit RJ45 port

• MAC Address Table

  16 K

• Switching Capacity

  Whole-Device Performance: 14.8 Gbps

  Port Performance: 8.8 Gbps

• Packet Forwarding Rate

  Whole-Device Performance: 11.01 Mpps

  Port Performance: 6.55 Mpps

• Internal Cache

  4 Mbits

• PoE Power Supply

• PoE Standard

  IEEE 802.3af,IEEE 802.3at

• PoE Power Pin

  8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)

• PoE Port

  PoE: Ports 1 to 24

• Max. Port Power

  30 W

• PoE Power Budget

  230 W

• Software Function

• Long Range

  Ports 1 to 24: up to 300 m.

  Long range performance may vary depend on camera model or cable condition.

• VIP Port

  Ports 1 to 8: data on VIP ports is preferentially forwarded when bandwidth resources are insufficient.

• Port Isolation

  Ports 1 to 24: port isolation mode to improve network security

  Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.

• PoE Watchdog

  Ports 1 to 24: auto detect and restart the cameras that do not respond.

• Link Aggregation

  Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection.

  Support static link aggregation.

  Support 1 aggregation group(s).

• Loop Prevention

  Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default.

  Support 802.1D STP.

  Suppport 802.1w RSTP.

• VLAN

  VLAN is used for network scale planning and network health improvement.

  Support 802.1Q.

  Configurable VLAN ID from 1-4094.

  Support Trunk, Access port mode.

  Support Max. 4094 VLAN.

• HPP

  Support one-click activation and remote management via Hik-Partner Pro. Functions supported:

  1. Display the port rate.

  2. Display the port bandwidth utilization rate.

  3. Display the PoE power usage.

  4. Display topology information.

  5. Display the alarm status.

  6. Restart ports and devices.

  7. Enable port long-rage mode.

  8. Remotely upgrade the device.

• System Maintenance

  Support device management via web.

  Support DHCP Client. Enabled by default for dynamic assignment of management IP addresses.

  Support Super IP, which is a fixed IP address (10.180.190.200) for direct access.

  Support management via Hik-Central Pro.

  Support remote management via Hik-Partner Pro.

  Support cable detection. Abnormal open circuits and short circuits as well as network cable length can be detected.

  Supports 802.1ab LLDP for peer device discovery.

  Support port mirroring for fault locating.

• Approval

• EMC

  CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015)

• Safety

  CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition)), CE-LVD (EN 62368-1: 2014+A11: 2017)

• Chemistry

  CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006)
